Reconditioned Dell Smart-UPS
- 2.7k Watts / 3.0k V
- Input 208V / Output 208V
- Interface Port DB-9 RS-232
- SmartSlot
- Carries a full two-year warranty
Technical Specs
Output
Output Power Capacity 2700 Watts / 3000 VA
Max Configurable Power 2700 Watts / 3000 VA
Nominal Output Voltage 208V
Output Voltage Distortion Less than 5%
Output Frequency (sync to mains) 47 – 53 Hz for 50 Hz , 57 – 63 Hz for 60 Hz nominal
Topology Line interactive
Waveform Type Sine wave
Output Connections
| (6) NEMA 5-15R |  |
| (3) NEMA 5-20R |  |
| (1) NEMA L5-20R |  |
Input
Nominal Input Voltage 120V
Input Frequency 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
NEMA 5-20P
Cord Length 8ft (2.44meters)
Input voltage range for main operations 131 – 268V
Transfer Time 2 ms typical
Physical
Maximum Height 3.5 inches (89mm)
Maximum Width 19.0 inches (483mm)
Maximum Depth 26.0 inches (660mm)
Rack Height 2U
Net Weight 96.0 lbs. (43.64kg)
Shipping Weight 125.0 lbs. (56.82kg)
